| Dimensions (mm) | Rated Load (kN) | Rated Load (kgf) | Bearing Designation | Mounting Dimensions (mm) | Constant | Axial Load Coefficient | Weight (kg) | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d | D | B | C2 | γ1 （Minimum） | γ (Minimum) | Cr | Cor | Cr | Cor | db | da | γa (Maximum) | γb (Maximum) | e | Y2 | Y3 | Y0 | (reference) | |
| 750 | 1220 | 365 | 365 | 9.5 | 9.5 | 12500 | 29500 | 1270000 | 3000000 | 750KH31+K | 855 | 1125 | 8 | 8 | 0.37 | 2.7 | 1.8 | 1.8 | 1730 |
| 750 | 1090 | 250 | 250 | 7.5 | 7.5 | 7350 | 18100 | 750000 | 1850000 | 750KH30+K | 830 | 1025 | 6 | 6 | 0.37 | 2.7 | 1.8 | 1.8 | 798 |
| 714.375 | 1016 | 339.725 | 339.725 | 3.3 | 6.4 | 9500 | 26200 | 970000 | 2670000 | * M383240D-N1 / M383210+K | 756 | 953 | 6.4 | 3.3 | 0.35 | 2.9 | 1.9 | 1.9 | 924 |
| 710 | 1150 | 345 | 345 | 9.5 | 9.5 | 11100 | 26100 | 1130000 | 2660000 | 710KH31+K | 800 | 1055 | 8 | 8 | 0.37 | 2.7 | 1.8 | 1.8 | 1440 |
| 710 | 1030 | 236 | 236 | 7.5 | 7.5 | 6600 | 16100 | 675000 | 1650000 | 710KH30+K | 785 | 965 | 6 | 6 | 0.37 | 2.7 | 1.8 | 1.8 | 671 |
| 690 | 980 | 355 | 355 | 6 | 6 | 9400 | 26000 | 960000 | 2650000 | 690KH9801+K | 729 | 917 | 5 | 5 | 0.35 | 2.9 | 1.9 | 1.9 | 891 |
| 670 | 1090 | 336 | 336 | 7.5 | 7.5 | 10300 | 23500 | 1050000 | 2400000 | 670KH31+K | 733 | 1008 | 6 | 6 | 0.37 | 2.7 | 1.8 | 1.8 | 1270 |
| 670 | 980 | 230 | 230 | 7.5 | 7.5 | 6300 | 14600 | 640000 | 1490000 | 670KH30+K | 717 | 920 | 6 | 6 | 0.37 | 2.7 | 1.8 | 1.8 | 601 |
| 609.6 | 787.4 | 171.45 | 171.45 | 3.3 | 6.4 | 3450 | 9600 | 350000 | 980000 | * EE649241D / 649310+K | 634 | 749 | 6.4 | 3.3 | 0.37 | 2.7 | 1.8 | 1.8 | 216 |
| 600 | 820 | 160 | 160 | 6 | 6 | 3300 | 8300 | 340000 | 845000 | 600KH8201+K | 637 | 774 | 5 | 5 | 0.42 | 2.4 | 1.6 | 1.6 | 258 |
| 600 | 760 | 115 | 115 | 6 | 5 | 1500 | 5000 | 152000 | 510000 | 600KH7601+K | 635 | 723 | 4 | 5 | 0.44 | 2.3 | 1.5 | 1.5 | 133 |
| 596 | 760 | 115.25 | 115 | 6 | 5 | 1500 | 5000 | 152000 | 510000 | 596KH7601+K | 633 | 723 | 4 | 5 | 0.44 | 2.3 | 1.5 | 1.5 | 137 |
| 595.312 | 844.55 | 296.862 | 296.862 | 3.3 | 6.4 | 6850 | 19000 | 700000 | 1930000 | * M280049D / M280010+K | 630 | 790 | 6.4 | 3.3 | 0.33 | 3 | 2 | 2 | 558 |
| 590 | 770 | 150 | 160 | 6 | 5 | 2600 | 7300 | 265000 | 740000 | 590KH7701+K | 620 | 732 | 4 | 5 | 0.39 | 2.6 | 1.7 | 1.7 | 191 |
| 571.5 | 812.8 | 285.75 | 285.75 | 3.3 | 6.4 | 6850 | 18600 | 700000 | 1900000 | * M278749D-N3 / M278710+K | 603 | 759 | 6.4 | 3.3 | 0.33 | 3 | 2 | 2 | 502 |
| 570 | 710 | 140 | 150 | 4 | 4 | 2230 | 6450 | 228000 | 660000 | 570KH7101+K | 593 | 680 | 3 | 3 | 0.32 | 3.1 | 2.1 | 2.1 | 130 |
| 560 | 920 | 280 | 280 | 7.5 | 7.5 | 7300 | 15400 | 740000 | 1570000 | 560KH31+K | 635 | 845 | 6 | 6 | 0.39 | 2.6 | 1.7 | 1.7 | 762 |
| 558.8 | 736.6 | 196.85 | 196.85 | 3.3 | 6.4 | 3950 | 11200 | 400000 | 1150000 | * LM377449D / LM377410+K | 583 | 696 | 6.4 | 3.3 | 0.35 | 2.9 | 1.9 | 1.9 | 237 |
| 550 | 750 | 130 | 150 | 6 | 5 | 2630 | 6350 | 269000 | 650000 | 550KH7501+K | 583 | 707 | 4 | 5 | 0.49 | 2.1 | 1.4 | 1.4 | 196 |
| 540 | 710 | 140 | 1150 | 5 | 4 | 2180 | 5650 | 222000 | 575000 | 540KH7101+K | 568 | 675 | 3 | 4 | 0.4 | 2.5 | 1.7 | 1.6 | 151 |
