| Dimensions（mm) | Rated load(KN) | Maximum radial load Pu (KN) | Bearing Designation | Legend Code | Outer diameter protrusion (mm) | Factory assembly Height（mm) H | Weight(kg) | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d | D | B | C | γ1(Minimum) | γ2 | Cr | Cor | (reference) | A | f | (reference) | ||||
| 180 | 406.42 | 224 | 224 | 0.6 | 1 | 2360 | 4400 | 1510 | * STF2U180-4g3 | 9 | 25 | 0.145 | 113.16 | -0.010~0 | 164 |
| 180 | 406.42 | 224 | 224 | 0.6 | 1 | 2360 | 4400 | 1510 | 2U180-4 | 9 | 25 | 0.145 | 113.16 | -0.010~0 | 164 |
| 180 | 406.42 | 406.42 | 224 | 2.1 | 1.5 | 2610 | 5150 | 1610 | * 3PL180-2Ag2 | 1 | 10 | 0.058 | 113.155 | -0.012~0 | 169 |
| 180 | 406.42 | 224 | 224 | 2.1 | 1.5 | 2610 | 5150 | 1610 | 3PL180-2A | 1 | 10 | 0.058 | 113.155 | -0.012~0 | 169 |
| 180 | 406.4 | 224 | 220 | 2.1 | 1.5 | 2050 | 3750 | 1580 | 3U180-3 | 12 | 10 | 0.058 | 113.205 | -0.015~0 | 162 |
| 180 | 406.4 | 224 | 220 | 2.1 | 1.5 | 2050 | 3750 | 1580 | * 3U180-2g2 | 12 | 10 | 0.058 | 113.16 | -0.012~0 | 162 |
| 180 | 406.4 | 217 | 217 | 2.1 | 1.5 | 2550 | 5000 | 1560 | 3U180-2 | 12 | 10 | 0.058 | 113.16 | -0.012~0 | 162 |
| 180 | 406.4 | 217 | 217 | 2.1 | 1.5 | 2550 | 5000 | 1560 | * 3PL180-1Bg2 | 1 | 10 | 0.058 | 113.16 | -0.012~0 | 164 |
| 180 | 406.4 | 217 | 217 | 2.1 | 1.5 | 2550 | 5000 | 1560 | 3PL180-1B | 1 | 10 | 0.058 | 113.16 | -0.012~0 | 164 |
| 180 | 406.42 | 176 | 170 | 2 | 3 | 1650 | 2850 | 1220 | 2U180-8 | 8 | 25 | 0.145 | 113.2 | -0.015~0 | 128 |
| 180 | 406.42 | 171.04 | 171.04 | 3 | 4 | 1560 | 2660 | 1150 | * STF2U180-7g3 | 8 | 25 | 0.25 | 113.155 | ±0.010 | 123 |
| 180 | 406.42 | 171.04 | 171.04 | 3 | 4 | 1560 | 2660 | 1150 | 2U180-7 | 8 | 25 | 0.25 | 113.155 | ±0.010 | 123 |
| 180 | 406.42 | 171.04 | 170 | 2 | 3 | 1650 | 2850 | 1220 | 2U180-5A | 8 | 36.5 | 0.212 | 113.2 | -0.015~0 | 124 |
| 180 | 406.42 | 171.04 | 170 | 2 | 3 | 1650 | 2850 | 1220 | 2U180-5 | 8 | 25 | 0.145 | 113.2 | -0.015~0 | 124 |
| 180 | 406.42 | 171.04 | 171.04 | 0.6 | 1 | 1900 | 3300 | 1150 | * STF2U180-3g3 | 9 | 25 | 0.145 | 113.16 | -0.010~0 | 125 |
| 180 | 406.42 | 171.04 | 171.04 | 0.6 | 1 | 1900 | 3300 | 1150 | 2U180-3 | 9 | 25 | 0.145 | 113.16 | -0.010~0 | 125 |
| 180 | 406.42 | 171.04 | 171.04 | 2.1 | 4 | 2060 | 3800 | 1220 | 3PL180-3E | 1 | 25 | 0.145 | 113.155 | ±0.005 | 129 |
| 180 | 406.42 | 171.04 | 171.04 | 2.1 | 4 | 2060 | 3800 | 1220 | 3PL180-3B | 1 | 25 | 0.145 | 113.155 | -0.010~0 | 129 |
| 179.984 | 406.43 | 224.25 | 220 | 3 | 4 | 2250 | 4250 | 1570 | * STF2U179Z-14gA5 | 11 | 60 | 0.175 | 113.181 | ±0.015 | 161 |
| 179.984 | 406.43 | 224.25 | 220 | 3 | 4 | 2250 | 4250 | 1570 | 2U179Z-14 | 11 | 60 | 0.175 | 113.181 | ±0.015 | 161 |
