| Dimensions（mm) | Rated load(KN) | Bearing Designation | Install Dimensions(mm) | Constant | Axial Load Coefficient. | Weight(kg) | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d | D | B2 | C | γ (Minimum) | γ1 （Minimum） | Cr | Cor | da（Minimum） | Db(Minimum) | γa（Maximum） | γb(Maximum） | e | Y2 | Y3 | Y0 | (reference) | |
| 240 | 400 | 209 | 168 | 5 | 1.5 | 2220 | 4450 | 600 | 900 | 240 KBE 4003+L | 267 | 384 | 4 | 1.5 | 0.33 | 3 | 2 |
| 240 | 407 | 216 | 185 | 6 | 1.5 | 2220 | 4450 | — | — | 240 KBE 4002+L | 285 | 393 | 5 | 1.5 | 0.33 | 3 | 2 |
| 240 | 400 | 160 | 128 | 5 | 1.5 | 1620 | 3050 | 600 | 900 | 240 KBE 031+L | 267 | 378 | 4 | 1.5 | 0.39 | 2.6 | 1.7 |
| 240 | 400 | 128 | 114 | 5 | 1.5 | 1180 | 2190 | 600 | 900 | 240 KBE 31+L | 267 | 380 | 4 | 1.5 | 0.43 | 2.3 | 1.6 |
| 240 | 360 | 170 | 142 | 4 | 1 | 1350 | 2870 | — | — | 240 KBE 3601+L | 274 | 351 | 3 | 1 | 0.39 | 2.6 | 1.7 |
| 240 | 360 | 115 | 92 | 4 | 1.5 | 1020 | 2040 | 700 | 900 | 240 KBE 030+L | 261 | 344 | 3 | 1.5 | 0.35 | 2.9 | 2 |
| 240 | 360 | 92 | 82 | 4 | 1.5 | 780 | 1490 | 700 | 900 | 240 KBE 30+L | 261 | 344 | 3 | 1.5 | 0.39 | 2.6 | 1.7 |
| 234.95 | 384.175 | 238.125 | 193.675 | 6.4 | 1.5 | 2090 | 4450 | — | — | * H247549/H247510D+L | 276 | 369 | 6.4 | 1.5 | 0.33 | 3 | 2 |
| 234.95 | 355.6 | 152.4 | 111.125 | 7 | 1.5 | 1030 | 2340 | — | — | * 96935/96140D+L | 273 | 342 | 7 | 1.5 | 0.59 | 1.7 | 1.1 |
| 234.95 | 327.025 | 114.3 | 82.55 | 6.4 | 1.5 | 805 | 1880 | — | — | * 8575/8520D+L | 264 | 316 | 6.4 | 1.5 | 0.41 | 2.5 | 1.7 |
| 234.95 | 311.15 | 98.425 | 73.025 | 3.5 | 0.8 | 640 | 1610 | — | — | * LM446349/LM446310D+L | 259 | 304 | 3.5 | 0.8 | 0.36 | 2.8 | 1.9 |
| 230 | 410 | 180 | 120 | 5 | 1.5 | 1770 | 3150 | — | — | 230 KBE 4101+L | 278 | 395 | 4 | 1.5 | 0.55 | 1.8 | 1.2 |
| 230 | 400 | 188 | 136 | 7.5 | 1.5 | 1620 | 3000 | — | — | 230 KBE 4002+L | 274 | 379 | 6 | 1 | 0.44 | 2.3 | 1.5 |
| 230 | 380 | 200 | 160 | 5 | 1.5 | 1930 | 3800 | — | — | 230 KBE 3801+L | 270 | 367 | 4 | 1.5 | 0.33 | 3 | 2 |
| 228.6 | 425.45 | 209.55 | 158.75 | 7 | 1.5 | 2200 | 4000 | — | — | * EE700091/700168D+L | 281 | 406 | 7 | 1.5 | 0.33 | 3 | 2 |
| 228.6 | 400.05 | 187.325 | 136.525 | 10.4 | 1.5 | 1620 | 3000 | — | — | * EE430900/431576D+L | 277 | 379 | 10.4 | 1.5 | 0.44 | 2.3 | 1.5 |
| 228.6 | 355.6 | 158.75 | 117.475 | 6.8 | 0.8 | 1190 | 2470 | — | — | * EE130902/131402D+L | 265 | 341 | 6.8 | 0.8 | 0.33 | 3 | 2 |
| 228.6 | 355.6 | 152.4 | 114.3 | 6.4 | 1.5 | 1310 | 2590 | — | — | * HM746646/HM746610D+L | 266 | 345 | 6.4 | 1.5 | 0.47 | 2.1 | 1.4 |
| 228.6 | 355.6 | 152.4 | 111.125 | 7 | 1.5 | 1030 | 2340 | — | — | * 96900/96140D+L | 270 | 342 | 7 | 1.5 | 0.59 | 1.7 | 1.1 |
| 228.6 | 355.6 | 152.4 | 111.125 | 6.8 | 1.5 | 1190 | 2470 | — | — | * EE130902/131401D+L | 265 | 340 | 6.8 | 1.5 | 0.33 | 3 | 2 |
