| Dimensions（mm) | Rated load(KN) | Rated load{kgf} | Bearing Designation | Dimensions（mm) | Install Dimensions(mm) | Weight(kg) | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d | D | T | γ (Minimum) | Ca | C0a | Ca | C0a | d1 | d1 | B1 | B2 | C | A | Da (Minimum） | da (Maximum） | γa (Maximum) | (reference) | |
| 1060 | 1770 | 426 | 15 | 27300 | 128000 | 2780000 | 13000000 | 294/1060 | 1630 | 1385 | 153 | 400 | 205 | 610 | 1440 | 1560 | 12 | 4030 |
| 1000 | 1670 | 402 | 15 | 26200 | 123000 | 2670000 | 12500000 | 294/1000 EM | 1550 | 1300 | 145 | 385 | 195 | 590 | 1360 | 1470 | 12 | 3450 |
| 900 | 1520 | 372 | 15 | 24100 | 109000 | 2460000 | 11100000 | 294/900 EM | 1420 | 1165 | 134 | 359 | 185 | 530 | 1220 | 1330 | 12 | 2700 |
| 900 | 1520 | 372 | 15 | 19900 | 96000 | 2030000 | 9750000 | 294/900 | 1450 | 1164 | 135 | 360 | 185 | 520 | 1190 | 1315 | 12 | 2760 |
| 850 | 1440 | 354 | 15 | 23100 | 102000 | 2360000 | 10400000 | 294/850 | 1315 | 1095 | 127 | 342 | 172 | 501 | 1160 | 1260 | 12 | 2250 |
| 800 | 1360 | 335 | 15 | 20900 | 91000 | 2130000 | 9250000 | 294/800 EM | 1250 | 1030 | 120 | 324 | 163 | 462 | 1080 | 1180 | 12 | 1920 |
| 800 | 1360 | 335 | 15 | 16600 | 77500 | 1700000 | 7900000 | 294/800 | 1300 | 1030 | 121 | 323 | 162 | 445 | 1060 | 1175 | 12 | 2010 |
| 750 | 1280 | 315 | 15 | 18900 | 81000 | 1920000 | 8250000 | 294/750 EM | 1170 | 964 | 113 | 305 | 153 | 436 | 1020 | 1110 | 12 | 1600 |
| 750 | 1280 | 315 | 15 | 15100 | 69000 | 1530000 | 7000000 | 294/750 | 1220 | 970 | 128 | 301 | 152 | 429 | 995 | 1105 | 12 | 1680 |
| 710 | 1220 | 308 | 15 | 17700 | 76000 | 1810000 | 7750000 | 294/710 EM | 1110 | 917 | 111 | 298 | 149 | 415 | 965 | 1060 | 12 | 1430 |
| 710 | 1220 | 308 | 15 | 14300 | 65500 | 1460000 | 6700000 | 294/710 | 1160 | 920 | 132 | 292 | 148 | 407 | 950 | 1050 | 12 | 1500 |
| 670 | 1150 | 290 | 15 | 15700 | 67000 | 1600000 | 6800000 | 294/670 EM | 1050 | 864 | 104 | 280 | 141 | 387 | 905 | 1000 | 12 | 1200 |
| 670 | 1150 | 290 | 15 | 12500 | 56000 | 1270000 | 5700000 | 294/670 | 1090 | 870 | 105 | 278 | 140 | 385 | 895 | 990 | 12 | 1250 |
| 30 | 1090 | 280 | 12 | 14400 | 61000 | 1470000 | 6200000 | 294/630 EM | 995 | 815 | 101 | 270 | 137 | 365 | 860 | 950 | 10 | 1050 |
| 630 | 1090 | 280 | 12 | 11600 | 51500 | 1180000 | 5250000 | 294/630 | 1040 | 830 | 100 | 268 | 136 | 365 | 845 | 935 | 10 | 1100 |
| 600 | 1030 | 258 | 12 | 10100 | 43000 | 1030000 | 4400000 | 294/600 | 985 | 780 | 93 | 249 | 127 | 345 | 800 | 885 | 10 | 895 |
| 600 | 800 | 122 | 5 | 3300 | 17800 | 340000 | 1810000 | 292/600 | 772 | 688 | 39 | 117 | 58 | 321 | 690 | 735 | 4 | 169 |
| 560 | 980 | 250 | 12 | 11900 | 48500 | 1210000 | 4950000 | 294/560 EM | 890 | 727 | 90 | 241 | 122 | 328 | 770 | 850 | 10 | 756 |
| 560 | 980 | 250 | 12 | 9600 | 42000 | 980000 | 4300000 | 294/560 | 935 | 744 | 91 | 242 | 124 | 325 | 755 | 835 | 10 | 800 |
| 560 | 850 | 175 | 7.5 | 5700 | 26700 | 580000 | 2730000 | 293/560 | 810 | 687 | 59 | 168 | 85 | 310 | 695 | 750 | 6 | 354 |
