| Dimensions（mm) | Rated load(KN) | Rated load{kgf} | Bearing Designation | Install Dimensions(mm) | Constant | Axial Load Coefficient. | Weight(kg) | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d | D | B | C2 | γ1 （Minimum） | γ (Minimum) | Cr | Cor | Cr | Cor | db | da | γa (Maximum) | γb (Maximum) | e | Y2 | Y3 | Y0 | (reference) | |
| 1500 | 1915 | 1220 | 1105 | spec. | spec. | 44500 | 168000 | 4550000 | 17100000 | 1500KV1901 | 2 | 1580 | 1815 | 13 | 6 | 0.33 | 3 | 2 | |
| 1200.15 | 1593.85 | 990.6 | 990.6 | 4.8 | 12.7 | 39500 | 128000 | 4000000 | 13100000 | * 1200KV1551 | 2 | 1249 | 1506 | 12.7 | 4.8 | 0.33 | 3 | 2 | |
| 1006.475 | 1295.4 | 764 | 764 | 4.8 | 12.7 | 23100 | 76500 | 2360000 | 7800000 | 1006KV1251 | 2 | 1055 | 1225 | 12.7 | 4.8 | 0.33 | 3 | 2 | |
| 939.8 | 1333.5 | 952.5 | 952.5 | 4.8 | 12.7 | 31500 | 92000 | 3200000 | 9400000 | * 939KV1351 | 2 | 996 | 1246 | 12.7 | 4.8 | 0.33 | 3 | 2 | |
| 938.212 | 1270 | 825.5 | 825.5 | 4.8 | 12.7 | 26100 | 79500 | 2660000 | 8100000 | * 938KV1251 | 2 | 990 | 1190 | 12.7 | 4.8 | 0.33 | 3 | 2 | |
| 901.7 | 1295.4 | 901.7 | 914.4 | 4.8 | 12.7 | 30500 | 88000 | 3100000 | 8950000 | * 901KV1251 | 2 | 960 | 1205 | 12.7 | 4.8 | 0.33 | 3 | 2 | |
| 863.6 | 1219.2 | 876.3 | 889 | 4.8 | 12.7 | 28300 | 81000 | 2890000 | 8250000 | * 863KV1252 | 2 | 911 | 1139 | 12.7 | 4.8 | 0.33 | 3 | 2 | |
| 863.6 | 1181.1 | 666.75 | 666.75 | 4.8 | 12.7 | 19600 | 62000 | 1990000 | 6300000 | * 863KV1153 | 2 | 901 | 1092 | 12.7 | 4.8 | 0.33 | 3 | 2 | |
| 863.6 | 1130.3 | 669.925 | 669.925 | 4.8 | 12.7 | 19600 | 62000 | 1990000 | 6300000 | * 863KV1151 | 2 | 901 | 1067 | 12.7 | 4.8 | 0.33 | 3 | 2 | |
| 840 | 1170 | 840 | 840 | 7 | 7 | 25900 | 76000 | 2640000 | 7050000 | * 840KV1151 | 2 | 885 | 1099 | 7 | 7 | 0.33 | 3 | 2 | |
| 825.5 | 1168.4 | 844.55 | 844.55 | 4.8 | 12.7 | 25900 | 76000 | 2640000 | 7050000 | * 825KV1151 | 2 | 873 | 1089 | 12.7 | 4.8 | 0.33 | 3 | 2 | |
| 800 | 1120 | 820 | 820 | 7 | 7 | 23800 | 69000 | 2430000 | 7050000 | * 800KV1151 | 2 | 843 | 1050 | 7 | 7 | 0.33 | 3 | 2 | |
| 785 | 1040 | 560 | 560 | 4.8 | 9.7 | 14200 | 41500 | 1450000 | 4200000 | * 785KV1051 | 2 | 820 | 981 | 9.7 | 4.8 | 0.42 | 2.4 | 1.6 | |
| 785 | 1030 | 605 | 605 | 6 | 7.5 | 15300 | 47500 | 1560000 | 4850000 | 785KV1002 | 2 | 817 | 971 | 6 | 5 | 0.42 | 2.4 | 1.6 | |
| 762 | 1079.5 | 787.4 | 787.4 | 4.8 | 12.7 | 22800 | 63500 | 2330000 | 6500000 | * 762KV1052 | 2 | 802 | 1007 | 12.7 | 4.8 | 0.33 | 3.1 | 2.1 | |
| 762 | 1066.8 | 723.9 | 736.6 | 5 | 12.7 | 21000 | 59500 | 2150000 | 6050000 | * 762KV1051 | 2 | 803 | 995 | 12.7 | 5 | 0.33 | 3.1 | 2.1 | |
| 750 | 1220 | 750 | 750 | 9.6 | 9.6 | 24900 | 59000 | 2540000 | 6000000 | 750KV81 | 2 | 855 | 1125 | 8 | 8 | 0.37 | 2.7 | 1.8 | |
| 750 | 1090 | 515 | 515 | 7.5 | 7.5 | 14700 | 36500 | 1500000 | 3700000 | 750KV80 | 2 | 830 | 1025 | 6 | 6 | 0.37 | 2.7 | 1.8 | |
| 749.3 | 1066.8 | 723.9 | 736.6 | spec. | 12.7 | 20600 | 58000 | 2100000 | 5900000 | * 749KV1051 | - | 800 | 994 | 12.7 | — | 0.33 | 3.1 | 2.1 | |
| 749.3 | 990.6 | 605 | 605 | 3.3 | 6.4 | 15200 | 47000 | 1550000 | 4800000 | * 749KV9951 | - | 782 | 938 | 6.4 | 3.3 | 0.33 | 3 | 2 | |
