| Dimensions（mm) | Rated load(N) | Rated speed (min)-1 | Bearing Designation | Install Dimensions(mm) | Weight(kg) | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d | D | B | γ(Minimum) | γ1 | EW | Cr | Cor/sub> | Grease lubrication | Oil lubrication | Da (Minimum） | dLa (Minimum) | da (Maximum） | Da (Minimum） | γa (Maximum) | (reference) | |
| 85 | 130 | 22 | 1.1 | 1 | 118 | 38500 | 43000 | 13000 | 20000 | N 1017RXHZTPKR | 91.5 | 91 | 123.5 | 120 | 1 | 0.796 |
| 85 | 130 | 22 | 1.1 | 1 | 118 | 38500 | 43000 | 12000 | 17000 | N 1017RXZTPKR | 91.5 | 91 | 123.5 | 120 | 1 | 0.87 |
| 85 | 130 | 22 | 1.1 | 1 | 118 | 38500 | 43000 | 8800 | 13000 | N 1017RSZTPKR | 91.5 | 91 | 123.5 | 120 | 1 | 0.87 |
| 80 | 125 | 22 | 1.1 | 1 | 113 | 36500 | 39500 | 14000 | 21000 | N 1016RXHZTPKR | 86.5 | 86 | 118.5 | 115 | 1 | 0.785 |
| 80 | 125 | 22 | 1.1 | 1 | 113 | 36500 | 39500 | 13000 | 17000 | N 1016RXZTPKR | 86.5 | 86 | 118.5 | 115 | 1 | 0.859 |
| 80 | 125 | 22 | 1.1 | 1 | 113 | 36500 | 39500 | 9200 | 14000 | N 1016RSZTPKR | 86.5 | 86 | 118.5 | 115 | 1 | 0.859 |
| 75 | 115 | 20 | 1.1 | 1 | 105 | 29600 | 31500 | 15000 | 23000 | N 1015RXHZTPKR | 81.5 | 81 | 108.5 | 107 | 1 | 0.565 |
| 75 | 115 | 20 | 1.1 | 1 | 105 | 29600 | 31500 | 14000 | 19000 | N 1015RXZTPKR | 81.5 | 81 | 108.5 | 107 | 1 | 0.623 |
| 75 | 115 | 20 | 1.1 | 1 | 105 | 29600 | 31500 | 9900 | 15000 | N 1015RSZTPKR | 81.5 | 81 | 108.5 | 107 | 1 | 0.623 |
| 70 | 110 | 20 | 1.1 | 1 | 100 | 27800 | 28500 | 16000 | 24000 | N 1014RXHZTPKR | 76.5 | 76 | 103.5 | 102 | 1 | 0.546 |
| 70 | 110 | 20 | 1.1 | 1 | 100 | 27800 | 28500 | 15000 | 20000 | N 1014RXZTPKR | 76.5 | 76 | 103.5 | 102 | 1 | 0.604 |
| 70 | 110 | 20 | 1.1 | 1 | 100 | 27800 | 28500 | 10000 | 16000 | N 1014RSZTPKR | 76.5 | 76 | 103.5 | 102 | 1 | 0.604 |
| 65 | 100 | 18 | 1.1 | 1 | 91 | 23600 | 24500 | 17000 | 27000 | N 1013RXHZTPKR | 71.5 | 71 | 93.5 | 93 | 1 | 0.437 |
| 66 | 100 | 18 | 1.1 | 1 | 91 | 23600 | 24500 | 16000 | 22000 | N 1013RXZTPKR | 71.5 | 71 | 93.5 | 93 | 1 | 0.484 |
| 65 | 100 | 18 | 1.1 | 1 | 91 | 23600 | 24500 | 11000 | 17000 | N 1013RSZTPKR | 71.5 | 71 | 93.5 | 93 | 1 | 0.484 |
| 60 | 95 | 18 | 1.1 | 1 | 86.1 | 22200 | 22100 | 18000 | 28000 | N 1012RXHZTPKR | 66.5 | 66 | 88.5 | 88 | 1 | 0.372 |
| 60 | 95 | 18 | 1.1 | 1 | 86.1 | 22200 | 22100 | 17000 | 23000 | N 1012RXZTPKR | 66.5 | 66 | 88.5 | 88 | 1 | 0.411 |
| 60 | 95 | 18 | 1.1 | 1 | 86.1 | 22200 | 22100 | 12000 | 18000 | N 1012RSZTPKR | 66.5 | 66 | 88.5 | 88 | 1 | 0.411 |
| 55 | 90 | 18 | 1.1 | 1 | 81 | 20700 | 19700 | 19000 | 30000 | N 1011RXHZTPKR | 61.5 | 61 | 83.5 | 83 | 1 | 0.313 |
| 55 | 90 | 18 | 1.1 | 1 | 81 | 20700 | 19700 | 18000 | 25000 | N 1011RXZTPKR | 61.5 | 61 | 83.5 | 83 | 1 | 0.344 |
