| Dimensions（mm) | Rated load(KN) | Rated load{kgf} | Rated speed (min)-1 | Bearing Designation | Dimensions (mm) | Install Dimensions(mm) | Weight(kg) | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d | D | B | γ (Minimum) | Cr | Cor | Cr | Cor | Grease lubrication | Oil lubrication | Fixed end bearing | Free-end bearing | dOH | Displacement | Da (Minimum） | da (Maximum） | γa (Maximum) | (reference) |
| 300 | 460 | 218 | 216 | 2 | 1.5 | 2670 | 5850 | 272000 | 600000 | 300 | RS-5060 | RS-5060NR | 178 | 19 | 476 | 7 | 8 |
| 280 | 420 | 190 | 189 | 2 | 1.5 | 2170 | 4700 | 221000 | 480000 | 340 | RS-5056 | RS-5056NR | 154 | 17.5 | 436 | 7 | 8 |
| 260 | 400 | 190 | 189 | 2 | 1.5 | 2130 | 4500 | 217000 | 460000 | 360 | RS-5052 | RS-5052NR | 154 | 17.5 | 416 | 7 | 8 |
| 240 | 360 | 160 | 159 | 1.5 | 1.1 | 1570 | 3350 | 160000 | 340000 | 400 | RS-5048 | RS-5048NR | 130 | 14.5 | 376 | 6 | 7 |
| 220 | 340 | 160 | 159 | 1.5 | 1.1 | 1510 | 3100 | 154000 | 320000 | 430 | RS-5044 | RS-5044NR | 130 | 14.5 | 356 | 6 | 7 |
| 200 | 310 | 150 | 149 | 1.3 | 1.1 | 1310 | 2650 | 133000 | 270000 | 480 | RS-5040 | RS-5040NR | 120 | 14.5 | 324 | 5 | 6 |
| 190 | 290 | 136 | 135 | 1.3 | 1.1 | 1120 | 2230 | 114000 | 227000 | 500 | RS-5038 | RS-5038NR | 110 | 12.5 | 304 | 5 | 6 |
| 180 | 280 | 136 | 135 | 1.3 | 1.1 | 980 | 1910 | 100000 | 195000 | 530 | RS-5036 | RS-5036NR | 110 | 12.5 | 294 | 5 | 6 |
| 170 | 260 | 122 | 121 | 1.3 | 1.1 | 860 | 1680 | 88000 | 171000 | 600 | RS-5034 | RS-5034NR | 99 | 11 | 270 | 4 | 6 |
| 160 | 240 | 109 | 108 | 1.3 | 1.1 | 695 | 1370 | 71000 | 140000 | 630 | RS-5032 | RS-5032NR | 89 | 9.5 | 247 | 3 | 6 |
| 150 | 225 | 100 | 99 | 1.3 | 1 | 620 | 1210 | 63500 | 124000 | 670 | RS-5030 | RS-5030NR | 81 | 9 | 232 | 3 | 6 |
| 140 | 210 | 95 | 94 | 1.1 | 1 | 550 | 1040 | 56000 | 106000 | 710 | RS-5028 | RS-5028NR | 77 | 8.5 | 217 | 3 | 5 |
| 130 | 200 | 95 | 94 | 1.1 | 1 | 535 | 1000 | 54500 | 102000 | 750 | RS-5026 | RS-5026NR | 77 | 8.5 | 207 | 3 | 5 |
| 120 | 180 | 80 | 79 | 1.1 | 1 | 400 | 750 | 40500 | 76500 | 850 | RS-5024 | RS-5024NR | 65 | 7 | 188 | 3 | 5 |
| 110 | 170 | 80 | 79 | 1.1 | 1 | 385 | 695 | 39000 | 71000 | 900 | RS-5022 | RS-5022NR | 65 | 7 | 175.4 | 2.5 | 5 |
| 100 | 150 | 67 | 66 | 1 | 0.6 | 320 | 585 | 32500 | 59500 | 1000 | RS-5020 | RS-5020NR | 54 | 6 | 155.4 | 2.5 | 4 |
| 95 | 145 | 67 | 66 | 1 | 0.6 | 310 | 565 | 32000 | 57500 | 1100 | RS-5019 | RS-5019NR | 54 | 6 | 150.4 | 2.5 | 4 |
| 90 | 140 | 67 | 66 | 1 | 0.6 | 305 | 540 | 31000 | 55000 | 1100 | RS-5018 | RS-5018NR | 54 | 6 | 145.4 | 2.5 | 4 |
| 85 | 130 | 60 | 59 | 0.6 | 0.6 | 256 | 445 | 26200 | 45500 | 1200 | RS-5017 | RS-5017NR | 48 | 5.5 | 134.5 | 2.5 | 3 |
| 80 | 125 | 60 | 59 | 0.6 | 0.6 | 251 | 430 | 25600 | 43500 | 1200 | RS-5016 | RS-5016NR | 48 | 5.5 | 129.5 | 2.5 | 3 |
